Time：2025-09-25
Edit：JFU Bearing
625VV
625VV
|
Company
|
JFU Rolling Bearing | ||
|
Description
|
|||
|
ORDER
Bearing No.
|
625VV | ||
|
SD
Inside Diameter
|
5 | mm | |
|
D
Outside Diameter
|
16 | mm | |
|
B
Width
|
5 | mm | |
|
R1
Chamfer Dimension
|
0.3 | mm | |
|
CR1
Basic Dynamic Load Ratings
|
1730 | N | |
|
COR1
Basic Static Load Ratings
|
670 | N | |
|
CR2
Basic Dynamic Load Ratings
|
177 | kgf | |
|
COR2
Basic Static Load Ratings
|
68 | kgf | |
|
LG
Limiting Speed Grease
|
36000 | rpm | |
|
DB
Abutment and Fillet Dimensions max.
|
7.5 | mm | |
|
DB1
Abutment and Fillet Dimensions min.
|
13.8 | mm | |
|
RB
Abutment and Fillet Dimensions max.
|
0.3 | mm | |
|
MASS
Mass
|
4.86 | g |
