Time：2025-09-28
Edit：JFU Bearing
2202
2202
|
ORDER
Bearing No.
|
2202 | ||
|
SD
Inside Diameter
|
15 | mm | |
|
D
Outside Diameter
|
35 | mm | |
|
B
Width
|
14 | mm | |
|
R
Chamfer Dimension
|
0.6 | mm | |
|
CR1
Basic Dynamic Load Ratings
|
7800 | N | |
|
COR1
Basic Static Load Ratings
|
1850 | N | |
|
CR2
Basic Dynamic Load Ratings
|
795 | kgf | |
|
COR2
Basic Static Load Ratings
|
188 | kgf | |
|
LG
Limiting Speed Grease
|
18000 | rpm | |
|
LO
Limiting Speed Oil
|
22000 | rpm | |
|
DA1
Abutment and Fillet Dimensions min.
|
19 | mm | |
|
DA2
Abutment and Fillet Dimensions max.
|
31 | mm | |
|
RA
Abutment and Fillet Dimensions max.
|
0.6 | mm | |
|
E
Constant
|
0.5 | ||
|
Y2
Axial load factors
|
1.9 | ||
|
Y3
Axial load factors
|
1.3 | ||
|
Y0
Axial load factors
|
1.3 | ||
|
MASS
Mass
|
0.055 | kg |
