Time：2025-09-26
Edit：JFU Bearing
7901A5DB
7901A5DB
|
ORDER
Bearing No.
|
7901A5DB | ||
|
SD
Inside Diameter
|
12 | mm | |
|
D
Outside Diameter
|
24 | mm | |
|
B
Width
|
6 | mm | |
|
R
Chamfer Dimension
|
0.3 | mm | |
|
R1
Chamfer Dimension
|
0.15 | mm | |
|
CR1
Basic Dynamic Load Ratings
|
5200 | N | |
|
COR1
Basic Static Load Ratings
|
3550 | N | |
|
CR2
Basic Dynamic Load Ratings
|
530 | kgf | |
|
COR2
Basic Static Load Ratings
|
360 | kgf | |
|
FO
Factors
|
0 | ||
|
LG
Limiting Speed Grease
|
30000 | rpm | |
|
LO
Limiting Speed Oil
|
43000 | rpm | |
|
A
Eff. Load center
|
14.4 | mm | |
|
DA1
Abutment and Fillet Dimensions min.
|
14.5 | mm | |
|
DA2
Abutment and Fillet Dimensions max.
|
22.8 | mm | |
|
RA
Abutment and Fillet Dimensions max.
|
0.3 | mm |
